Gurjan Plywood
Gurjan core and panels lend natural strength to plywood. Imported from South-East Asian countries, Gurjan is a fully mature, high density hardwood, which makes it naturally strong & resistant to all kinds of organisms. These veneers when compressed under exterme pressure yield a panel density of above 800kg/m3 greatly superseding standard IS requirements and making it highly densified & homogenous.
IT is Inherently Borer and termite resistant, displays anti warp features and has extreme hardness and strength.
Properties | Specifications |
---|---|
Strength grade HS Strength class | D50 |
Bending parallel to grain | 16.0 N/mm2 |
Tension parallel to grain | 9.6 N/mm2 |
Compression parallel to grain | 15.2 N/mm2 |
Compression perpendicular to grain | 4.5/3.5 N/mm2 |
Shear parallel to grain | 2.20 N/mm2 |
Modulus of elasticity | mean 15000 N/mm2 |
Modulus of elasticity | minimum 12600 N/mm2 |
Characteristic density | 650 kg/m3 |
Average density | 7800 kg/m3 |
Strength class for joint design | D50 |
Compared to teak as | 100 |
Weight | 105 |
Retention of shape | 50 |
Shear | 105 |
Hardness | 95 |
Nail / screw holding power | 100 |
